GETTING STARTED
37
G
ETTING STARTED
This chapter describes the GLC-9000 in a nutshell, including the
main features, front and rear panel descriptions, and the power up
sequence.
Preparation
Voltage Line
Selection Before power is turned on,
ensure the line voltage is
correct for the environment.
The line voltage is shown on
the rear panel.
Voltage: 100/120/220/230V
±10% Frequency: 50~60Hz




Warning Ensure a three pronged grounded power socket is
used.
Fuse Ensure the correct fuse is used
before power up. (Fuse:
T0.4A/250V)

   









 
 
2 3 4 5 1 6

EUT AC Line In Before connecting power to the
EUT AC Line In, confirm the
EUT input power and test
requirements do not exceed the
EUT AC Line In requirements.
Voltage Range: 85V ~ 250V / 50
~ 60Hz

   



 



 
 

2 3 4 5 1 6
Caution * EUT : 10A(max), 1500VA(max)
