Installation diagram /kf4 – Yokogawa RotaMASS 3-Series User Manual
Page 80
9. EXPLOSION PrOTECTEd TyPE INSTrUMENTS
9-4
IM 01R04B05-00E-E 3rd edition July 30, 2010 -00
all Rights Reserved. Copyright © 2005, Rota Yokogawa
[Integral type]
Terminator
Rotamass
(Flowmeter)
FFout+
FFout–
+
–
+
–
Field Instrument
Field Instrument
Safe Area
Hazardous Area
Terminator
Saftey Barrier
L/+
N/–
Safe Area
Power supply
AC or DC
F09105.EPS
Installation diagram /KF4 :
