APPENdIX 1. LIST OF PArAMETErS FOr EACH BLOCK OF rOTAMASS
a-9
IM 01R04B05-00E-E 3rd edition July 30, 2010 -00 all Rights Reserved. Copyright © 2005, Rota Yokogawa
relative
Index
Index Parameter Name Factory default Write
Mode
Explanation
22 2022 SEnSoR_CaL_DatE - o/S Sets/indicates the dates of the last sensor
calibration.
23 2023 SEnSoR_CaL_WHo YoKoGaWa o/S Sets/indicates the name of the person
responsible for the last sensor calibration.
24 2024 LIn_tYPE linear with
input(1) - the linearization type of sensor output.
Rotamass is “linear with input”.
25 2025 MaSS_FLoW_VaLuE 0 - Mass flow value
26 2026 MaSS_FLoW_VaLuE_RanGE *) - Mass flow value range. Depends on
detector size.
27 2027 MaSS_FLoW_VaLuE_FtIME 3 s - time constant of damping for the mass flow
rate calculation. Setting range: 0.1 to 200 s
28 2028 MaSS_FLoW_LoWCut 0 o/S Low cut value of the mass flow.
Setting range 0 to 10% of
MaSS_FLoW_VaLuE_RanGE.Eu100
29 2029 VoLuME_FLoW_VaLuE - - Volume flow value
30 2030 VoLuME_FLoW_VaLuE_RanGE *) - Volume flow value range. Depends on
detector size.
31 2031 VoLuME_FLoW_VaLuE_FtIME 3 s time constant of damping for the volume
flow rate calculation. Setting range: 0.1 to
200 s
32 2032 VoLuME_FLoW_LoWCut 0 o/S Lowcut value of the volume flow. Setting
range 0 to 10% of
VoLuME_FLoW_VaLuE_RanGE.Eu100
33 2033 DEnSItY_VaLuE - - Density flow value
34 2034 DEnSItY _VaLuE_RanGE 5 kg/l - Density value range
35 2035 DEnSItY_VaLuE_FtIME 3 s - time constant of damping for the density
calculation. Setting range: 0.1 to 200s
36 2036 DEnSItY_LoWCut 0 o/S Lowcut value of the density. Setting range
0 to 10% of DEnSItY_VaLuE_RanGE.
Eu100
37 2037 tEMPERatuRE_VaLuE - - temperature value
38 2038 tEMPERatuRE _VaLuE_RanGE 230°C - Range of temperature value. Standard
version: -200 to 230°C; High temperature
version: 0 to 400°C.
39 2039 tEMPERatuRE _VaLuE_ FtIME 3 s - time constant of damping for the temperature
calculation. Setting range: 0.1 to 200s
40 2040 ConCEntR_MEaS_VaLuE - - Concentration measurement value
41 2041 ConCEntR_MEaS_VaLuE_RanGE 100 - Range of concentration measurement.
42 2042 ConCEntR_MEaS_VaLuE_ FtIME 10s - time constant of damping for the
concentration measurement calculation.
Setting range: 0.1 to 200 s
43 2043 ConCEntR_MEaS_ LoWCut 0 o/S Lowcut value of the concentration measure-
ment. Setting range 0 to 10% of ConCEntR_
MEaS_VaLuE_RanGE.Eu100
44 2044 nEt_FLoW_VaLuE - - net flow value
45 2045 nEt_FLoW_VaLuE_RanGE *) - netflow value range. Depend on detector
size.
46 2046 nEt_FLoW_VaLuE_ FtIME 3s - time constant of damping for the net flow
rate calculation. Setting range: 0.1 to 200s
47 2047 nEt_FLoW_ LoWCut 0 o/S Low cut value of the net flow. Setting range
0 to 10% of nEt_FLoW_VaLuE_RanGE.
Eu100
48 2048 VELoCItY_VaLuE 0.0 – the Velocity of the Medium
not available for gas measurement (/Ga)
49 2049 VELoCItY_unItS_InDEX m/sec o/S this parameter shows the unit of the Velocity;
Range: m/s or ft/s
50 2050 DISPLaY_SELECt_1 Mass flow - Value displayed on the 1st line of the LCD
display.
51 2051 DISPLaY_SELECt_2 Volume flow - Value displayed on the 2nd line of the LCD
display.
52 2052 DISPLaY_SELECt_3 Density - Value displayed on the 3rd line of the LCD
display.
53 2053 DISPLaY_SELECt_4 temperature - Value displayed on the 4th line of the LCD
display.
*) Depends on detector size. For RCCF31 not combined with detector, data for RCCS36 are stored.
