APPENdIX 1. LIST OF PArAMETErS FOr EACH BLOCK OF rOTAMASS
a-3
IM 01R04B05-00E-E 3rd edition July 30, 2010 -00 all Rights Reserved. Copyright © 2005, Rota Yokogawa
36 1036 BLoCK_aLM - - the block alarm is used for all configura-
tion, hardware, connection failure or
system problems in the block. the cause
of the alert is entered in the subcode field.
the first alert to become active will set the
active status in the Status attribute. as
soon as the unreported status is cleared
by the alert reporting task, another block
alert may be reported without clearing the
active status, if the sub code has changed.
37 1037 aLaRM_SuM - - the current alert status, unacknowledged
states, unreported states, and disabled
states of the alarms associated with the
function block.
38 1038 aCK_oPtIon 0xffff auto
39 1039 WRItE_PRI 0 auto Priority of the alarm generated by clearing
the write lock. 0, 1, 3 to 15
40 1040 WRItE_aLM - - this alert is generated if the write lock pa-
rameter is cleared.
41 1041 ItK_VER 5 * - Version number of inter operability test by
Fieldbus Foundation applied to Rotamass.
42 1042 SoFt_REV - - Rotamass software revision number.
43 1043 SoFt_DESC - Yokogawa internal use.
44 1044 SIM_EnaBLE_MSG (Spaces) auto Software switch for simulation function.
45 1045 DEVICE_StatuS_1 - - Device Status (VRC setting etc.)
46 1046 DEVICE_StatuS_2 - - Sensor failure etc.
47 1047 DEVICE_StatuS_3 - - Device status (function block setting)
48 1048 DEVICE_StatuS_4 - - Device status (function block setting)
49 1049 DEVICE_StatuS_5 - - Device status (function block setting)
50 150 DEVICE_StatuS_6 - - not used for Rotamass.
51 1051 DEVICE_StatuS_7 - - not used for Rotamass.
52 1052 DEVICE_StatuS_8 - - not used for Rotamass.
53 1053 SoFtDWn_PRotECt 0x01 - Defines whether to accept software
downloads.
0x01: unprotected
0x01: protected
54 1054 SoFtDWn_FoRMat 0x01 - Selects the software download method.
0x01: Standard
55 1055 SoFtDWn_Count 0 - Indicates the number of times the internal
FlashRoM was erased.
56 1056 SoFtDWn_aCt_aREa 0 - Indicates the RoM number of the currently
working FlashRoM.
57 1057 SoFtDWn_MoD_REV 1,0,0,0,0,0,0,0,0 - Indicates the software module revision
erature value on the LCD display.
58 1058 SoFtDWn_ERRoR 0 - Indicates the error during a software
download.
* Status on July 2010; ItK_VER can change due to further development
