APPENdIX 8. dEVICEVIEWEr WINdOW EXECUTEd FrOM FIELdMATE ANd PrM
a-79
IM 01R04B05-00E-E 3rd edition July 30, 2010 -00 all Rights Reserved. Copyright © 2005, Rota Yokogawa
Figure A8.5 Others
Table A8.5 Others
It1 in o/S mode(a-29) alarm It1 Block is in o/S mode. (a-29)
[Remedy]: Change the It1 Block Mode.target(It1.MoDE_BLK.target) to auto or other mode.
In addition, check that RB Block Mode.actual(RB.MoDE_BLK.actual) is set to auto mode.
If it is an unused function, set aLaRM_PERFoRM bit6 to 0.
It1 in Man mode(W-27) Warning It1 Block is in Man mode. (W-27)
[Remedy]: Change the It1 Block Mode.target(It1.MoDE_BLK.target) to auto or other mode.
It1 not Scheduled(W-57) Warning It1 Block is not scheduled. (W-57)
[Remedy]: Make a schedule of It1 Block.
It1 Conf. Err(W-71) Warning It1 Clock Period(It1.CLoCK_PER) is smaller than It1 Period of Execution(EXECutIon_PERIoD).
(W-71) [Remedy]: Change the value as It1 Clock Period(It1.CLoCK_PER) is larger than It1 Period of
Execution(EXECutIon_PERIoD).
It1 total Backup Err(W-73) Warning It1 total Backup failed. Last It1 output.Value(It1.LaSt.VaLuE) could not save. (W-73)
[Remedy]: Contact the nearest office or service center.
It2 in o/S mode(a-30) alarm It2 Block is in o/S mode. (a-30)
[Remedy]: Change the It2 Block Mode.target(It2.MoDE_BLK.target) to auto or other mode.
In addition, check that RB Block Mode.actual(RB.MoDE_BLK.actual) is set to auto mode.
If it is an unused function, set aLaRM_PERFoRM bit7 to 0.
It2 in Man mode(W-28) Warning It2 Block is in Man mode. (W-28)
[Remedy]: Change the It2 Block Mode.target(It2.MoDE_BLK.target) to auto or other mode.
It2 not Scheduled(W-58) Warning It2 Block is not scheduled. (W-58)
[Remedy]: Make a schedule of It2 Block.
It2 Conf. Err(W-72) Warning It2 Clock Period(It2.CLoCK_PER) is smaller than It2 Period of Execution(EXECutIon_PERIoD).
(W-72) [Remedy]: Change the value as It2 Clock Period(It2.CLoCK_PER) is larger than It2 Period of
Execution(EXECutIon_PERIoD).
It2 total Backup Err(W-74) Warning It2 total Backup failed. Last It2 output.Value(It2.LaSt.VaLuE) could not save. (W-74)
[Remedy]: Contact the nearest office or service center.
PID in o/S mode(a-31) alarm PID Block is in o/S mode. (a-31)
[Remedy]: Change the PID Block Mode.target(PID.MoDE_BLK.target) to auto or other mode.
In addition, check that RB Block Mode.actual(RB.MoDE_BLK.actual) is set to auto mode.
If it is an unused function, set aLaRM_PERFoRM bit8 to 0.
PID in Bypass Mode(W-61) Warning PID Block is in Bypass mode. (W-61)
[Remedy]: Change the value of Bypass(PID.BYPaSS) to oFF.
