APPENdIX 1. LIST OF PArAMETErS FOr EACH BLOCK OF rOTAMASS
a-2 IM 01R04B05-00E-E 3rd edition July 30, 2010 -00 all Rights Reserved. Copyright © 2005, Rota Yokogawa
16 1016 REStaRt - - allows a manual restart to be initiated.
Several degrees of restart are possible.
they are 1: Run, 2: Restart resource,
3: Restart with defaults and 4: Restart
processor.
17 1017 FEatuRES 0x000a (Soft write
lock supported
Report supported) - used to show supported resource block
options. for the Rotamass.
18 1018 FEatuRE_SEL 0x000a (Soft write
lock supported
Report supported) auto used to select resource block options,
bit0: Scheduled
bit2: Event driven
bit2: Manufacturer specified
19 1019 CYCLE_tYPE 0x0001 (Sched-
uled) - Identifies the block execution methods
available for this resource.
20 1020 CYCLE_SEL 0x0001 (Sched-
uled) auto used to select the block execution method
for this resource.
21 1021 MIn_CYCLE_t 3200 - time duration of the shortest cycle interval
of which the resource is capable.
22 1022 MEMoRY_SIZE 0 - available configuration memory in the emp-
ty resource. to be checked before
attempting a down load.
23 1023 nV_CYCLE_t 0 - Interval between writing copies of nV
parameters to non-volatile memory. Zero
means never.
24 1024 FREE_SPaCE 0 - Percent of memory available for further
configuration. RotaMaSS has zero which
means a preconfigured resource.
25 1025 FREE_tIME 0 - Percent of the block processing time that
is free to process additional blocks. Sup-
ported only with PID function.
26 1026 SHED_RCaS 640000 (20s) auto time duration at which to give up on com-
puter writes to function block Rcas
locations. Supported only with PID function.
27 1027 SHED_Rout 640000 (20s) auto time duration at which to give up on
computer writes to function block Rout
locations. Supported only with PID function.
28 1028 FauLt_StatE 1 - Condition set by loss of communication to
an output block, failure promoted to an
output block or a physical contact. When
fail-safe condition is set, then output
function blocks will perform their FSaFE
actions. Supported only with PID function.
29 1029 SEt_FStatE 1 (oFF) auto allows the fail-safe condition to be manually
initiated by selecting Set. Supported only
with PID function.
30 1030 CLR_FStatE 1 (oFF) auto Writing a Clear to this parameter will clear
the device fail-safe state if the field
condition, if any, has cleared. Supported
only with PID function.
31 1031 MaX_notIFY 3 - Maximum number of unconfirmed notify
messages possible.
32 1032 LIM_notIFY 3 auto Maximum number of unconfirmed alert no-
tify messages allowed.
33 1033 ConFIRM_tIME 640000 (20s) auto the minimum time between retries of alert
reports.
34 1034 WRItE_LoCK not locked auto If set, no writes from anywhere are
allowed, except to clear WRItE_LoCK.
Block inputs will continue to be updated.
1: not locked, 2: Locked
35 1035 uPDatE_EVt - - this alert is generated by any change to
the static data.
