Setup
CLS User’s Guide 83
Heat or Cool Cycle Time
From this menu you can set the Cycle Time for Time Proportioning
outputs.
NOTE
The Cycle Time menu will only be present if the output
type for the current loop is Time Proportioning.
Selectable range: 1-255 seconds.
SDAC Menus
If you attach the optional SDAC to an output, you must configure that
output for the SDAC using the following series of menus. The CLS will
also assign digital output #34 as a clock line for the SDAC. You won't
be able to assign another function to output #34 while any loop's output
is set to SDAC.
SDAC Mode
From this menu you can toggle the SDAC between current and voltage
output. The SDAC menus only appear if the output type for the loop is
set to SDAC.
Selectable values: Current or voltage.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
02 HEAT OUTPUT
CYCLE TIME ? 10 s
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 SDAC MODE ?
VOLTAGE
