Using the CLS
CLS User’s Guide 59
Press any key to exit this display. If at least one control output (heat or
cool) is enabled, you'll see this display:
• Press Yes to change the mode.
• Press Yes or No to switch between Manual, Automatic, and Tune.
• To exit this menu and return to the Single Loop Display without sav-
ing your changes, press Back.
• Press Enter to save your changes. If you have set the mode to Man-
ual, you can now set the manual heat and cool output levels.
Manual Output Levels
The Manual Output Levels menu will only appear if you have set the
current loop to Manual control. This menu lets you set the manual
output levels for the enabled outputs. The cool output menu is just like
the heat output menu, except that the word COOL replaces the word
HEAT in the display. You should see a display like the one below:
• Press Yes to change the output power.
• Then press Yes or No to select a new output power level.
• When you are satisfied with the power level you have chosen, press
Enter to store your changes.
• To discard your changes and return to Single Loop display, press
Back.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 CONTROL
STATUS ? AUTO
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 SET HEAT
OUTPUT ? 90%
