Appendix B: Enhanced Process Control
141
Minimum Input
Selectable Values: From the input loop PV minimum reading to the
maximum reading.
Minimum Output
NOTE
If you select a Min. Out other than 0%, one output will
never drop below Min. Out, even if the PV drops below the
Min. Input you specify.
Selectable Values: 0-100%
Maximum Input
Selectable Values: From the input loop PV minimum reading to the
maximum reading.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
02 HEAT RETRANS
MIN INP? 1000
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
02 HEAT RETRANS
MIN OUT%? 0%
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
02 HEAT RETRANS
MAX INP? 10000
