Using the CLS
CLS User’s Guide 57
Job Display
Job display appears only if:
• You have turned on the Remote Job Select function. (This function is
explained in Setup.)
• You have selected a job from the job load menu.
When you load a job, Job display shows you the following screen:
If you remotely loaded the job, Job display looks like this:
If you modify a job's parameters while the job is running, you'll see this
job message:
If an alarm occurs, the controller switches to Single Loop Display.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
JOB 3 RUNNING
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
JOB 3 RUNNING
REMOTELY LOADED
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
JOB 3 RUNNING
DATA MODIFIED
