124 CLS User’s Guide
Appendix A: Ramp Soak
Choosing an External Reset Input
Use this menu to select an external reset input. Toggle the input to reset
a profile to Ready state when it is in Run, Hold, or Wait mode. You can
make any of the eight digital inputs the external reset input.
Selectable Values: 1-8, or N (for no external reset).
Editing a Segment
Each profile is made up of several segments (up to 20). Use this menu to
choose the segment to edit.
Selectable Values: 1-20.
The first time you use this menu, it defaults to segment 1. when you
have finished editing a segment, the controller returns you to this menu
and goes to the next segment. This loop continues until you make a
segment the last segment of a profile.
Setting Segment Time
Use this menu to change the segment time.
Selectable Values: 000:00 to 999:59 (minutes or seconds, depending on
the selected time base).
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
C EXTERNAL RESET
INPUT NUMBER ? N
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
D EDIT SEGMENT
NUMBER ? 15
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
B SEGMENT 11
SEG TIME? 000:00
