64 CLS User’s Guide
Setup
Load a Job
Use this menu to load any one of 8 saved jobs from the controller's front
panel.
The following parameters are loaded as part of a job:
• PID constants, filter settings, setpoints and spread values
• Loop control status (Automatic or Manual) and output values (if the
loop is in Manual control).
• Alarm functions (Off, Alarm, Control), setpoints, high\low process
setpoints, high\low deviation setpoints and deadband settings, and
loop alarm delay.
WARNING
All current job settings will be overwritten if you select a
job from memory. Save your current programming to a
job number if you want to keep it.
If you have enabled the remote job control function, this menu will be
disabled; you will not be able to load a job from the front panel. If you
try it, you'll see the message below.
Save Setup to Job
Use this menu to save the job information for every loop to one of 8 jobs
in the CLS' battery-backed RAM.
If you have enabled the remote job control function, you will not be able
to save a job. If you try it, you'll see this message:
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
LOAD SETUP
FROM JOB ? 1
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
CANNOT LOAD JOB
REMOTE SELECT
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
SAVE SETUP
TO JOB ? 1
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
CANNOT SAVE JOB
REMOTE SELECT
