130 CLS User’s Guide
Appendix A: Ramp Soak
1. In Single Loop display, switch to the loop you want to edit.
2. Press the RAMP/SOAK key. The assigning menu appears. (See
menu in previous page)
3. Choose one of the available profiles and press ENTER.
4. Press BACK if you wish to return to Single Loop display without
saving any changes.
Assigning a different profile
To assign a new profile to a loop that already has one assigned, follow
these steps:
1. Press the RAMP/SOAK key three times.
2. Press the NO key. You will see the Reset Profile menu.
3. Press YES, then ENTER, to reset the profile. You will see the
Assign Profile menu. (See previous page.)
4. Choose one of the available profiles and press ENTER.
5. Press BACK if you wish to return to Single Loop display without
saving any changes.
Assigning a Profile to a Linear Input Loop
If you assign a profile to a loop with a linear input, these variables will
depend on the display format setting you chose for the linear input:
• Ready setpoint
• Segment setpoint
• Segment tolerance
Before you assign a profile to a linear input loop, Consult the following
table.
Display Format
setting
Effect on Parameter
-999 to 3000 Parameter is as set in profile.
-9999 to 30000 Controller multiplies your parameter by
ten.
-999.9 to 3000.0 Controller adds a decimal point and a zero
to your parameter.
-99.9 to 300.0 Controller divides your parameter by ten.
-9.999 to 30.000 Controller divides your parameter by 100.
0.999 to 3.00 Controller divides your parameter by
1000.
