92 CLS User’s Guide
Setup
Low Deviation Alarm Type
Use this menu to turn Off the low deviation alarm or set it to Alarm or
Control mode.
Selectable values: Off, Alarm, or Control.
Low Deviation Alarm Output Number
Use this menu to assign a digital output that activates when the loop is
in low deviation alarm.
NOTE
All digital outputs are OR'd together (combined). There-
fore you can assign more than one alarm to the same
output number, and that output will be On if any of those
alarms is On.
Selectable values: 1 and 34, as long as that output is not already used
for control or the SDAC clock, or you may select None.
Low Process Alarm Setpoint
Use this menu to set a low process alarm setpoint. The low process
alarm activates when the process variable goes below the low process
alarm setpoint. It deactivates when the process variable goes above the
low process alarm setpoint plus the deadband.
Selectable range: Any value within the input sensor's range.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 LO DEV ALARM
TYPE ? OFF
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
04 LO DEV ALARM
OUTPUT ? NONE
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 LO PROC ALARM
SETPT ? 0
º F
