Recommended wire gauges – Watlow CLS User Manual
Page 55
Installation
CLS User’s Guide 47
Recommended Wire Gauges
Watlow Anafaze recommends the following maximum distances and
wire gauges:
You may wish to use a shield, depending on your noise environment and
grounding problems. The above cables are shielded.
NOTE
These recommendations are conservative, to ensure that
your controller will operate reliably. Expect satisfactory
performance even if you must deviate slightly from a
design specification.
Distance
Wire Gauge
Recommended
Cable
4000 ft.
24 AWG
Belden #9729
Belden #9842
6000 ft.
22 AWG
Belden #9184
