96 CLS User’s Guide
Setup
Test Digital Output
Use this menu to select one of the digital alarm outputs to test in the
next menu.
Toggle Digital Output
Use this menu to manually toggle a digital output On or Off to test it.
(You select the output to test in the previous menu.) On may be Low or
High depending on the digital output polarity you set in the Output
Polarity menu. (All outputs are set to Off when you exit Manual I/O
Test menu.)
Selectable values: On or Off.
Keypad Test
Use this menu to test the keypad.
• Press any key to test the keypad. The CLS will display the name of
the key you have pressed.
• Press No twice to advance to the next menu.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
TEST DIGITAL
OUTPUT ? 34
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
DIGITAL OUTPUT
NUMBER 17? OFF
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
KEYPAD TEST
QUIT = "NO" + "NO"
