Setup

CLS User’s Guide 63

Set up Global Parameters Menu

The Set up Global Parameters menu looks like this:

Below is the setup global parameters menu tree. Notice the default
values inside the boxes.:

LOOP PROCESS UNITS

ALARM SETPOINT STATUS OUT%

SETUP GLOBAL
PARAMETERS ?

Setup Global Parameters?

Load setup from job? 1

Save setup to job? 1

Job select dig inputs?

NONE

Job sel dig ins active?

LOW

Output override dig
input? NONE

Override dig in active?
LOW

Startup alarm delay?
0 MINS

Keyboard lock status?
OFF

Power up output status?
OFF

Controller address? 1

Communications
baud rate? 9600

Communications
protocol? ANA

Communications err
check? BCC

AC line freq.?
60 HERTZ

Dig out polarity on alarm?
LOW

EPROM information
