Appendix A: Ramp Soak
CLS User’s Guide 121
Setting the R/S Time Base
The R/S time base menu is in the Setup Globals main menu.
Use this menu to set the time base in all your R/S profiles.
Selectable Values: Hours/Mins or Mins/Secs.
Editing R/S Parameters
You can reach the rest of the menus in this section from the Setup
Ramp/Soak profile main menu. This menu is located between the Setup
Loop Alarms main menu and the Manual I/O Test main menu.
Answering Yes to this prompt allows you to setup or edit R/S profiles.
Choosing a Profile to Edit
Use this menu to choose a profile to set up or edit.
Selectable Values: A to Q (17 profiles).
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
RAMP/SOAK TIME
BASE? HOURS/MINS
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
SETUP RAMP/SOAK
PROFILE?
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
EDIT RAMP & SOAK
PROFILE? A
