134 CLS User’s Guide
Appendix A: Ramp Soak
Holding a Profile or Continuing from Hold
Use the profile mode menu to hold a profile or continue from Hold. The
next table shows the available modes.
Holding a profile
In Hold mode, all loop parameters stay at their current settings until you
change the mode or reset the profile. To put a profile in hold, follow
these steps:
• Press RAMP/SOAK key repeatedly until you see the R/S mode
menu.
• While the profile is running, the only mode you will be able select is
Hold.
• Press YES to hold the profile, and then ENTER to advance to the
next menu.
Continuing a profile
If a profile is holding and you want it to run, you can put it in Continue
mode.
• Press RAMP/SOAK key repeatedly until you see the R/S mode
menu
• While the profile is holding, the only mode you will be able select is
Cont (Continue).
• Press YES to continue the profile, and then ENTER to advance to the
next menu.
Current
Mode
Available
Mode
Description
Start Run Begin running the assigned profile.
Hold Cont Continue from user-selected hold. Profile runs
from the point when you put the profile in Hold
mode. (You cannot continue from a tolerance
hold or a trigger wait.)
After you choose this mode, the controller
switches back to Run mode.
Run Hold Hold the profile.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 A SEG01/05 R
SET MODE? HOLD
