82 CLS User’s Guide
Setup
Enable/Disable Heat or Cool Outputs
From this menu you can enable or disable the heat or cool output for the
current loop. If you want the loop to have PID control, you must enable
one output. You can also disable a heat or cool control output and use
the output pin for something else, like an alarm.
Selectable values: Enabled or Disabled.
Heat or Cool Output Type
This menu lets you set the output type.
This table shows the available output types.
For an expanded description of these output types, see Tuning and
Control.
Display
Code
Output
Type
Definition
TP Time
proportioning Percent output converted to a per-
cent duty cycle over the pro-
grammed cycle time.
DZC Distributed
Zero Crossing Output on/off state calculated for
every AC line cycle.
SDAC Serial DAC Output type for optional Serial
Digital to Analog Converter.
ON/OFF On / Off Output either full ON or full OFF.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
01 HEAT CONTROL
OUTPUT ? ENABLED
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
03 HEAT OUTPUT
TYPE ? TP
