32 CLS User’s Guide
Installation
TB-50 Connections
4 and 8 CLS TB-50 Connections.
If you install a Watlow Anafaze Serial Digital to Analog Converter
(SDAC), the CLS uses digital output #34 for a clock line. You cannot
use output #34 for anything else when you have an SDAC installed.
* The indicated outputs are dedicated to PID (or control) when enabled
in the loop setup. If one or both of a loop’s outputs are disabled, the
corresponding digital outputs become available for alarms or ramp/soak
events.
Pin Function
PID Output*
8CLS 4CLS
Pin Function
PID Output*
8CLS 4CLS
1 +5 Vdc 2 +5 Vdc
3 CTRL COM 4 CTRL COM
5 Not Used 6 Watchdog Timer
7 Pulse Input 8 Global Alarm
9 DIG output 1 Loop 1 heat Loop 1 heat 10 DIG output 34*
11 DIG output 2 Loop 2 heat Loop 2 heat 12 DIG output 33
13 DIG output 3 Loop 3 heat Loop 3 heat 14 DIG output 32
15 DIG output 4 Loop 4 heat Loop 4 heat 16 DIG output 31
17 DIG output 5 Loop 5 heat Pulse loop
heat 18 DIG output 30
19 DIG output 6 Loop 6 heat Loop 1 cool 20 DIG output 29
21 DIG output 7 Loop 7 heat Loop 2 cool 22 DIG output 28
23 DIG output 8 Loop 8 heat Loop 3 cool 24 DIG output 27
25 DIG output 9 Pulse loop
heat Loop 4 cool 26 DIG output 26
27 DIG output 10 Loop 1 cool Pulse loop
cool 28 DIG output 25
29 DIG output 11 Loop 2 cool 30 DIG output 24
31 DIG output 12 Loop 3 cool 32 DIG output 23
33 DIG output 13 Loop 4 cool 34 DIG output 22
35 DIG output 14 Loop 5 cool 36 DIG output 21
37 DIG output 15 Loop 6 cool 38 DIG output 20
39 DIG output 16 Loop 7 cool 40 DIG output 19
41 DIG output 17 Loop 8 cool 42 DIG output 18 Pulse loop
cool
43 DIG input 1 44 DIG input 2
45 DIG input 3 46 DIG input 4
47 DIG input 5 48 DIG input 6
49 DIG input 7 50 DIG input 8
