Using the CLS
CLS User’s Guide 55
If only one output is enabled (heat or cool, but not both), Single Loop
display looks like this:
From Single Loop Display,
• Press Yes to go to the next loop.
• Press No to go to the previous loop.
• Press the Back key once to go to Job display (if enabled) or Bar
Graph display.
• Press Enter twice to start Single Loop Scanning display. (The Single
Loop Scanning Display shows information for each loop in
sequence. Data for each loop displays for one second.)
• Press any key to stop scanning mode.
LOOP PROCESS UNITS
ALARM SETPOINT STATUS OUT%
02 160 º
F 0
180 AUTO 100
Control Status
Output Percentage
Heat
Output Percentage
Cool
Engineering Units
Process Variable
Setpoint
Loop Number
or Name
