Chapter 2 Configuration Parameters
32 9650-1201-01 Rev. M
Set Lead Groups
This parameter allows you to configure two custom lead groups (of 3 leads each) as described
in the 12-Lead ECG Monitoring insert.
Values are as follows:
Procedure
Follow these steps to configure custom lead groups:
Lead Group Default
This parameter allows you to select the default lead group. Refer to the 12-Lead ECG
Monitoring Operator’s Guide insert for details on each setting.
Values are as follows:
Possible Values: I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
Default: Custom Group 1: II, III, aVF
Custom Group 2: II, III, VI
Step Action
1. Press the Change Config softkey from the Main
System Configuration screen.
The Parameter Categories screen appears.
Select 12 LEAD, then press the Enter softkey.
2. From the list of options, select Set Lead Groups,
and press the Change Value softkey.
The Lead Group Configuration screen is
displayed.
3. Update the lead groups using the softkeys as
follows:
• Prev Lead or Next Lead — moves the
highlight to the previous or next lead.
• Change Lead — changes the selected lead.
Repeatedly pressing this key cycles the
selected lead though all twelve possibilities.
• Enter— returns you to the previous screen.
Enter Return
Next
Item Prev
Item
System Configuration
3 of 7
EtCO2
Options
Pace Set/Review
12 Lead Set/Review
Set/Review
Prev
Lead Enter
Change
Lead
Next
Lead
System Configuration
II III aVF
Custom Group 1
Custom Group 2
II III V1
Possible Values: Standard, Custom Group 1, Custom Group 2
Default: Standard
