Help Manual
16
3. Plug the cameras UHCCD01400KPA (USB2.0) into the computer;
4. Start ToupView;
5. Choose File>Twain:Select Device••• command to select the device
UHCCD01400KPA from the Select Source dialog;
6. Choose File>Twain:Acquire••• command. There should be a dialog box like below:
In this dialog, Video Resolution can be selected (dropdown list if it has). The Video
Source Property••• can be set by clicking the Setting••• button. Click the Capture
button to capture an image. This will create a new window and its title bar will be
assigned a digital as the
Image window name;
Check RGB/BGR to ensure the correct color encoding format.
Click x on to close the Twain:acquire dialog.
6.6 Save Ctrl+S
Choose File>Save command to immediately store the contents of the current
window to its file (the file listed on the window's title bar) while leaving the image still
