Help Manual
112
mouse button. Two radiuses with number and the units will be shown on the
Annulus ;
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
Here you can edit the corresponding object parameters to modify its properties;
2) The Appearance , Coordinates on Measurement sidebar will be enabled only
when a single object is selected. The Calculation will be effective for a single selected
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.12 Two Circles
14.12.1 Two Circle>Center+Radius
Draw two circles with Center+Radius method on the specified layer. After the two
circles are drawn, a line connecting these two circle centers will be drawn.
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
Here you can edit the corresponding object parameters to modify its properties;
2) The Appearance , Coordinates on Measurement sidebar will be enabled only
when a single object is selected. The Calculation will be effective for a single selected
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.12.2 Two Circle>Three Points
Draw two circles with Three Points method on the specified layer. After the two circles
are drawn, a line connecting these two circle centers will be drawn.
Note : 1) To check or modify the parameters of the selected object, just select a single
