Levenhuk C800 NG Digital Camera, USB 2.0 - Manual (Page 137)

Help Manual
129
the Resolution will be calculated and displayed simultaneously in the Resolution field.
9. If everything is ok, click Ok to end the calibration. The Magnification 10X (This is
the number you entered in the Magnification edit box) will be available in the
Magnification dropdown list box on the Video window toolbar ;
10. If you wish to make the measurement under this Magnification , choose 10X in
the above Magnification dropdown list box first and then choose Unit in the Unit
dropdown list box( ) which is just in the left of the
Magnification ’s dropdown list box(User can also choose Unit through
Option>Measurements••• menu, a dialog called Measurement will be brought up.
Click Length Unit page to display the Length Unit page and and checking Unit in the
Current item.
Now, you can measure the objects with the selected Unit at ease.
