Help Manual
111
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.10.2 Circle>Two Points
Choose Measurements>Circle>Two Points to draw circle with Two Points method on
the specified layer.
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
Here you can edit the corresponding object parameters to modify its properties;
2) The Appearance , Coordinates on Measurement sidebar will be enabled only
when a single object is selected. The Calculation will be effective for a single selected
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.10.3 Circle>Three Points
Choose Measurements>Circle>Three Points to draw circle with Three Points method
on the specified layer.
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
Here you can edit the corresponding object parameters to modify its properties;
2) The Appearance , Coordinates on Measurement sidebar will be enabled only
when a single object is selected. The Calculation will be effective for a single selected
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.11 Annulus
1. Find Annulus center 1 and click mouse button to mark the Annulus center;
2. Move mouse to let the first circle superpose the image circle, clicking the mouse
left button;
3. Move mouse to let the second circle superpose the image circle, clicking the left
