Help Manual
105
3. Move mouse to the 2nd point, click the left mouse to mark it again, a line with L1
and its length will be shown.
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
Here you can edit the corresponding object parameters to modify its properties;
2) The Appearance , Coordinates on Measurement sidebar will be enabled only
when a single object is selected. The Calculation will be effective for a single selected
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.4.2 Line> Horizontal Line
Draw a Horizontal Line between the two points on the specified layer.
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
Here you can edit the corresponding object parameters to modify its properties;
2) The Appearance , Coordinates on Measurement sidebar will be enabled only
when a single object is selected. The Calculation will be effective for a single selected
object or more selected objects. Its calculated items will depend on the selected
objects type (The type could be the same or could be different).
14.4.3 Line> Vertical Line
Draw a Vertical Line between the two points on the specified layer.
Note : 1) To check or modify the parameters of the selected object, just select a single
measurement object and the Measurement sidebar will be activated automatically.
