FEC Micro Nutrunner Operations Manual Chapter 7: System Operations (Rev. 2.1: 12/12)
Page 7-13
7.2.5 Parameter Data List
Item
[Unit]
Parameter No.
PARM
Data No.
D-NO
DATA
Torque/Angle
Method
Torque
[Nm]
01~08 10 Calibration torque (CAL value) ○
01~08 11 Peak Torque Low Limit ○
01~08 12 Peak Torque High Limit ○
01~08 13 Standard Torque ○
01~08 14 Speed Change Torque ○
01~08 16 Snug Torque ○
01~08 19 Torque Inhibit Limit ○
01~08 1A 1 Pulse Reverse Torque Limit ○
Angle
[deg]
01~08 20 Angle Low Limit ○
01~08 21 Angle High Limit ○
01~08 22 Standard Angle ○
Time
[sec]
01~08 40 Initial Time ○
01~08 41 Freerun Time Limit ○
01~08 42 Fastening Time Limit ○
Rotation
Speed
[rpm]
01~08 50 Initial Speed ○
01~08 51 Freerun Speed ○
01~08 52 Slowdown Speed ○
01~08 53 Torque Speed ○
01~08 54 Reverse Speed ○
01~08 55 1 Pulse Reverse Speed ○
Revolutions
[rev]
01~08 60 Freerun Revolutions ○
01~08 61 Torque Inhibit Revolutions ○
01~08 64 1 Pulse Reverse Time ○
01~08 68 Rundown Revolutions
Low Limit
○
01~08
69 Rundown Revolutions
High Limit
○
