FEC Micro Nutrunner Operations Manual
Chapter 2: Specifications (Rev. 2: 02/12)
Page 2-3
2.3
MNR Unit Specifications
UNIT TYPE
UAN-8
TOOL MOTOR TYPE
MFT-080M10
TOOL MAX. TORQUE
0.8 Nm
(7.08 in lb))
TOOL MAX. SPEED
1100RPM
OVERALL TOOL WEIGHT
605gram
MNR INPUT POWER SUPPLY
100 – 240VAC Single Phase 150watt max.
24VDC Output
MNR UNIT WEIGHT
556g
{
Parameter / Firmware Storage: Flash ROM
{
Fastening Method:
Torque / Angle
{
Data Communications:
RS232C for MNR User Console Software or Data Output
USB for MNR User Console Software (See 7.4.2)
2.4 Capability
{
{
{
{
Fastening Accuracy (Torque):
From 1/4 to full scale torque: 3 sigma scatter less than 5% of target torque.
{
{
{
{
Torque Display Resolution:
4-digit display with floating decimal point
(In display unit)
{
{
{
{
Angle Display Resolution:
1 degree.
Forward Max. count 9999 degree
Reverse Max. count 1999 degree
{
Torque transducer accuracy:
(0 - Full Scale) ±1.5%
{
Linearity of torque transducer: ± 0.5% of Full Scale value (Maximum).
