FEC Micro Nutrunner Operations Manual Chapter 3: System Description (Rev 2: 02/12)
Page 3-7
3.3.4 RS232C Data Format Description
The table below describes the data convention output from the RS232C serial port on the front
display.
Non-data bytes will be occupied by the hex character 20H.
Data Name Byte # Data Format Description
Cycle Count 1 ~ 4 0000-9999 Number is reset at Power Off
Spindle Number 7 ~ 8 01 Always Spindle 1
Parameter Number 12 ~ 13 1 – 8 Maximum 8 parameters
Peak Torque 16 ~20 0.234 Decimal point location fixed
Peak Torque Judgment 21
H: High Reject
L: Low Reject
ASCII space (20H) will apply if
judgment is accepted
Final Angle (degrees) 23 ~ 26 1234
4 digit number. No decimal
point used
Final Angle Judgment 27
H: High Reject
L: Low Reject
ASCII space (20H) will apply if
judgment is accepted
Final Torque 29 ~ 33 0.234 Decimal point location fixed
Final Torque Judgment 34
H: High Reject
L: Low Reject
ASCII space (20H) will apply if
judgment is accepted
1st Time 57 ~ 61 123.4 Decimal point location fixed
1st Time Judgment 62 H: High Reject
ASCII space (20H) will apply if
judgment is accepted
2nd Time 64 ~ 68 123.4 Decimal point location fixed
2nd Time Judgment 69 H: High Reject
ASCII space (20H) will apply if
judgment is accepted
Total Judgment 73
O: Accept A: Abnormal
X: Reject S: Stop
Carriage return 77 ODH
Line feed 78 OAH
