53MT6000 INSTRUCTION MANUAL
54 Database Editor
The number of control modules per Controller is dependent on the options purchased with the Controller.
MicroTools provides access for all four possible control modules (CON0 through CON3). The window for
each CON module contains the entries listed below.
When first opened, the Control Module window provides access to the General purpose parameters. A
module selection window is used to select which of the four CON modules to be displayed or modified.
Using the up & down arrow buttons, select the desired module.
The Controller Configuration mode consists of seven screens that allow configuration of the Controller. The
seven buttons shown at the top right of the configuration window activate these screens:
GENERAL
OUTPUT
SETPOINT
ALARM
TUNING
TREND
STATUS
Clicking a button causes a different Control Module configuration window to appear along with its associ-
ated parameters.
7.4.7.1 GENERAL Configurable Parameters
The database locations where these values are stored for CON0 are shown in brackets [ ]. Refer to
Figure 7-10 for parameter screen locations.
ENTRY EXPLANATION
Module: Selects the Module to be configured. Use the up or down
arrow buttons to cycle through the control module
selection.
Tagname: Tagname of the CON module [A00]
Engineering Unit: Engineering units [A01]
Control Display
Mode: Selects desired CONTROL mode from the choices below
[B339]:
Standard PID
Indicator
Manual Loader
Ration Controller
A/M Station
Ratio A/M Station
Reverse Switch: Selects output characteristics as follows [B339]:
PV Up - Out Up
PV Up - Out Down
Reverse Valve: Selects valve operating characteristics as follows [L109]:
20mA Opens
20 mA Closes
