1.2 Controller Model Numbers
The 53SL6000 controller model numbers are de-
scribed in Table 1-1.
Table 1-1. 53SL6000 Model Numbers
53 SL6 ♦ ♦ ♦ A ♦ ♦
Controllers 53
Design Designator
(includes analog inputs
1 and 2, analog output
1, discrete inputs 1 and
2, discrete outputs 1
and 2) SL6
Power Requirements:
120/240 V ac 0
24 V dc 1
Option Slot A Module:
None 0
Single Universal Analog Input
(analog input 3)
1
Dual Universal Analog Input
(analog inputs 3 and 4)
(Each universal analog input can
accept RTD, thermocouple,
millivolt, voltage, and
frequency inputs. Thermo-
couple inputs are linearized
by this module.)
2
Option Slot B Module:
None.
2 Discrete Input/2 Discrete
Output (discrete inputs 3
and 4, discrete outputs 3
and 4)
0
3
Design Level A
Communications Mode:
None 0
RS-485 (allows datalink connection) 1
RS-232 (allows connection to a
personal computer or a modem) 2
Enclosure:
Standard Panel Mount Case 0
1.3 Product Specifications
The 53SL6000 controller conforms to the following
specifications and complies with the following regu-
latory requirements:
Physical Characteristics
Weight < 1.5 kg (3 lb 5 oz)
Front Dimension 72 x 144 mm
(2 53/64 x 5 43/64 in)
Overall Length With Option Modules - 130.8 mm
(5.15 in)
Without Option Modules - 85.7
mm (3 3/8 in)
Panel Installation
Panel Cutout See Figure 2-1
Installation Depth Allow an additional 25.4 mm (1
inch) for rear plug removal and
insertion.
Mounting Position Flush panel mounting ± 60 °
Degree of Protection
Facial NEMA4 (IP64)
Housing NEMA1 (IP20)
Safety Classification
CSA Approved for Class 1,
Division 2 (planned).
FM FM Approved for Class 1,
Division 2 (planned)
Environmental Limits
Operating Ambient -5 to 50 ° C (23 to 122 ° F)
Temperature Limits
Storage/Transport -40 to 85 ° C (-40 to 185 ° F)
Ambient
Temperature Limits
Relative Humidity Limits
Humidity Limits 5 to 95%
(operation)
Humidity Limits 5 to 100%
(storage/transport)
Barometric 82.7 to 103.4 kPa
Pressure
(operation)
Barometric 13.8 to 103.4 kPa
Pressure
(storage/transport)
Thermal Shock ± 20 ° C/hr ( ± 68 ° F /hr)
(operation)
