Micromod Micro-DCI: 53SL6000 Single Loop Controller - Manual (Page 131)

Table C-6. Prompt-to-Datapoint Cross
Reference
DBase Module DBase
Parameter
Network
Reference
EZ [Abrt] L074
APLd L073
cM B016
dout C075
dPV C074
dPPV C072
EPb C079
Etd C081
Etr C080
KP C077
LPS B015
nrun L076
PLiM L072
run L075
StS B017
tLiM C073
tP C076
WP C078
Fnc K01 C082
K02 C083
K03 C084
K04 C085
K05 C086
K06 C087
oPr Ai.E L123
ALM.E L124
di7.E L120
di8.E L121
EZ.E L127
hLc.E L126
Pid.E L125
StP.E L122
PrG Ao1.i B043
Ao2.i B044
Ao3.i B045
chr.M B038
chr.A B039
chr.b B053
chr.c B054
do1.i B067
do2.i B068
do3.i B069
do4.i B070
do5.i B071
do6.i B072
do7.i B073
do8.i B074
doFb B041
EXrF B042
FiX B000
Table C-6. Prompt-to-Datapoint Cross
Reference
DBase Module DBase
Parameter
Network
Reference
Fnc.M B033
PrG
(cont)
Fnc.A B034
Fnc.b B035
Fnc.c B036
Fnc.d B037
Fnc.E B046
Fnc.F B047
LG1.M B055
LG1.A B056
LG1.b B057
LG2.M B058
LG2.A B059
LG2.b B060
LG3.M B061
LG3.A B062
LG3.b B063
LG4.M B064
LG4.A B065
LG4.b B066
PVt B040
PVt.2 B052
SchM B026
cS.A B027
cS.b B028
cS.c B029
cS.d B030
cS.E B031
cS.F B032
cS.h B048
cS.J B049
cS.K B050
cS.L B051
SYS bAUd B002
cKEY F003
dLE L113
dLP L112
dLS L114
iA B001
oPtA B006
oPtb B007
PKEY F002
tAG A000
C.5 Executing Controller Self Tests
via Datalink
The procedure to execute the controller self tests
via the datalink can be found in Appendix B, Main-
tenance and Parts List.
53SL6000 Instruction Manual Appendix C. Datalink Protocol
C-8
