Micromod Micro-DCI: 53SL6000 Single Loop Controller - Manual (Page 118)

B.1 Overview
This section provides a parts list and maintenance
procedures to replace the display assembly and
power supply board, to execute the self-test, and to
initialize the database. Also provided is calibration
information for the controller analog inputs and out-
puts.
B.2 Parts List
The controller parts breakdown is illustrated in Fig-
ure B-1 and the corresponding parts list is provided
in Table B-1. Item numbers in the table correspond
to the callouts in Figure B-1.
Appendix B: Maintenance and Parts List
Figure B-1. Illustrated Parts Breakdown
Appendix B. Maintenance and Parts List 53SL6000 Instruction Manual
PARTS
B-1
