CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 83
Symbol Default Designation Default
Severity
Default LED Default Relay
LVD Low Voltage Disconnect Minor BAT None
LVDA Low Voltage Disconnect Fail Minor BAT None
MCM Major Communication Fail Minor CTLR None
MDF Module Failure Minor RM None
MOR Measurement Out Of Range Minor RM None
MTC Module Type Conflict Warning None None
NNC Number Not Configured Warning None None
OSA Open String Minor BAT None
PFD Password At Default Warning None None
PGI Program Line Invalid Major None None
PHT Processor Halt RO None None
POR Number Did Not Respond Warning None None
RLS1 Redundancy Loss Minor RECT None
RPI Rectifier/Plant Inconsistency Warning None None
RTL Reserve Time Low Minor BAT None
SNC Shunt Not Configured Warning None None
STF Self Test Failed Minor CTLR CTLR
TPA Thermal Probe Failure Minor CTLR CTLR
URC User Relay Conflict Warning None None
VLA Very Low Voltage Critical BAT UR3
VSF Sense/Control Fuse Major CTLR CTLR
ZID ID Not Configured Major RECT None
Rectifier Alarm Defaults
Symbol Default Designation Default
Severity
Default LED Default Relay
ACF AC Fail Minor AC ACF
CLM Rectifier Current Limit RO None None
ERD Excess Rectifier Drain Minor RECT None
ETS External Transfer Shutdown Minor RECT None
HPA Half Power Minor RECT None
LCA Low Current Alarm Minor RECT None
LSF Load Share Fuse Minor RECT None
MACF Multiple AC Fail Major AC ACF
MAN Manual Off Minor RECT None
MFA Multiple Rectifier Fail Major RECT RFA
MMAN Multiple MAN Alarm Major RECT None
PHA Phase Or Low Output Minor AC None
