CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 116
Terminal Lugs for Bullet Style Breakers and TPS Fuses (1/4” on 5/8” centers)
Lug
Part #
STR
Wire GA
(Class B)
Flex
Wire GA
(Class I)
WP-91412
List
406021626 8 8 75
405347519 6 6 3
405347576 4 4 5
405348202 2 -- 54
405347683 -- 2 8
Lugs for 2-pole Adapter Bus
407817568 1/0 -- 179
407817550 2/0 1/0 180
407817576 -- 2/0 181
CC848756916 2-pole adapter bus kit
Terminal Lugs for CO Ground, Battery, Large Breakers and Fuses
(3/8” on 1” centers)
Lug
Part #
STR Wire GA
(Class B)
FlexWire GA
(Class I)
WP-91412 List
406332841 6 6 111
406338665 2 -- 121
407726041 -- 2 176
405348228 1/0 -- 56
405348236 2/0 1/0 57
406021725 -- 2/0 77
405348251 4/0 -- 59
405347923 -- 4/0 27
407890763 350 -- 186
407890748 -- 350 183
406335141* 750 -- 135
407890730* -- 750 184
*Battery Landings Only
