CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 81
Voltage Threshold Ranges and Default Values
The following table provides the ranges and factory default settings of key configurable voltage
thresholds in the Millennium II.
Voltage Threshold Ranges and Default Values
Low High Default
Very Low Voltage (VLV)
24V 20.00 25.50 23.00
48V 40.00 51.00 46.00
Battery on Discharge (BD)
24V Float 23.00 28.00 25.00
24V Boost 23.00 28.00 25.00
48V Float 46.00 55.00 51.00
48V Boost 46.00 55.00 51.00
High Float Voltage (HFV)
24V Float 24.75 29.75 26.50
24V Boost 25.75 31.75 26.50
48V Float 50.00 60.00 53.00
48V Boost 52.00 60.00 53.00
High Voltage Shutdown Alarm (HV)
24V Float 24.75 29.75 26.8
24V Boost 25.75 31.75 26.8
48V Float 50.00 60.00 53.6
48V Boost 52.00 60.00 53.6
Rectifier On Threshold (ROT)
24V 20.00 25.00 22.00
48V 40.00 51.00 44.00
Controller Alarm Severity, LED and Relay Default Values
The following tables provide the various controller alarms and their associated default severity
and LED assignments as well as rectifier specific alarms. These items may be reconfigured
through remote means.
Controller Alarm Severity, LED and Relay Default Values
Symbol Default Designation Default
Severity
Default LED Default Relay
AAC ACO Active RO None None
ABS Alarm Battery Supply Fuse Major CTLR CTLR
AMJ Auxiliary Major Major None None
AMN Auxiliary Minor Minor None None
ATA Alarm Test Active RO None None
