BSW Data Switch Card
Step
Action
Note Installation or replacement of this pack can be done “hot”; power removal is not
necessary.
1
Install two 407882133 standoffs on the MCR1 located just below TB1 connector in the
upper left hand corner.
2
Place BSW pack inside the 847950938 insulator.
3
Plug BSW pack into the P205 connector on the MCR1 board
4
Secure the BSW board to the standoffs with two 900562208 screws.
Note To install the Data Switch Extension board, please see the Basic Installation And
User’s Guide For The Millennium II Controller (167-792-181).
BSL Alarm Termination Board
An insulation displacement (punch down) type alarm terminal board (BSL3, 848741711) is
provided with the system. For a wire wrap type terminal board, order BSL4 (848749507) and
perform the following steps:
Step
Action
1
In the upper right hand corner of the MCR1 board, find the alarm board already
installed.
2
Remove the two screws holding the board at the top.
3
Holding the board on both sides, slowly, but firmly, remove the alarm board from the
P8 connector.
4
Connect the new alarm board to P8 and press down firmly, until the board is seated.
5
Secure the alarm board at the top using the two screws removed earlier.
