CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 5
1 Introduction
Document Objectives
This manual provides installation and maintenance information for the Lineage Power
CPS6000-M2 power system:
• Product Description
• Safety Information
• Installation Procedures
• Test and Acceptance
• Troubleshooting
• Controller and Rectifier Operations
• Product Warranty
Audience
Equipment Installers – Instructions for installation, test, and acceptance.
Equipment Users – Plant basics and troubleshooting.
CAUTION: This unit must be installed, serviced, and operated only by
skilled and qualified personnel who have the necessary knowledge and
practical experience with electrical equipment and who understand the
hazards that can arise when working on this type of equipment.
Applications
The 48V CPS6000-M2 is ideally suited for small central office (CO) applications and high end
huts and vaults.
Additional Product Documentation
For additional specification, engineering and installation information, refer to the following
drawings as needed. These drawings may be accessed on our web site at
http://lineagepower.com/ . Click on Energy Systems Products/CPS6000 Plants.
Drawing Description
H5694720 Ordering Guide
167-790-063 Remote Peripheral Monitoring (RPM)
157-010-202 210E Thermal Probe Multiplexer Module
167-792-182 Advanced Features User Guide For The
Millennium II
