CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 16
Specifications
AC Input
Input Distribution Terminal Blocks per rectifier fed from 20A breaker or fuse at the AC
service panel.
Wire Size 10 AWG minimum for individual feeds.
System Output
System Voltage -48V
Maximum Output Current:
Two Rectifier Shelves (G255) 450A charge, 500A discharge
Four Rectifier Shelves (G256) 800A charge, 1000A discharge
Maximum Recharge Current Installed rectifier capacity minus plant -48V load
Low-Voltage Disconnect 39 to 50 Vdc
Low-Voltage Reconnect 39 to 55 Vdc
Safety / Standards Compliance
Safety Agency Approvals Underwriters Laboratories (UL) Listed per Subject Letter 1801: Power
Distribution Center for Communications Equipment, and cUL Certified
(CSA 22.2 950): Safety of Information Technology Equipment
VDE licensed to VDE0805/EN60950
Rectifiers are individually UL Recognized (UL1950), cUL Certified
(CSA 22.2 234) or evaluated to EN60950 by an EC Notified Body, as
appropriate.
European Economic Community
(EEC) Directives EMC Directive 89/336/EEC, Low Voltage Directive 73/23/EEC as
amended by Marking Directive 93/68/EEC
Radiated and Conducted
Emissions FCC Part 15, Class A
EN55022 (CISPR22), Class A
Harmonics EN61000-3-2 (IEC61000-3-2)
Voltage Fluctuations EN61000-3-3 (IEC61000-3-3)
Electromagnetic Immunity Meets Telcordia GR-1089-CORE
Electrostatic Discharge EN61000-4-2 Level 3
RF Immunity IEC61000-4-3 Level 3, 10 V/m
EFT IEC61000-4-4 Level 3, No Error; Level 4, No Damage
Surge IEC 61000-4-5 Level 3, No Error; Level 4, No Damage
Conducted Immunity IEC 61000-4-6 Level 3, 10V
Voltage Dips, Interruptions, and
Variations IEC 61000-4-11
Environmental
Operating Ambient Temperature -20 to 45 °C
Altitude -200 to 13,000 feet (-61 to 3962 meters)
See Note 1
Humidity 10% to 95% non-condensing
Audible Noise < 60 dBA
Earthquake Rating Zone 2 or Zone 4, upper floors, depending on battery configuration
Note 1: For altitudes above 5000 feet, derate the temperature by 3.6 °F per 1000 feet. For altitudes above
1524 meters, derate the temperature by 0.656 degrees Celsius per 100 meters.
