GE Industrial Solutions CPS6000-M2 User Manual
Page 68
CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008
68
Clear Events: MENU > CONTROL / OPERATIONS > CLEAR EVENTS
Latched events may be cleared using this feature. Latched events remain active after their cause
is removed (retired) until manually cleared.
If the Alarm is a Latched Event and does not retire after performing this operation, the alarm
condition most likely still exists.
Uninstall Devices: MENU > CONTROL / OPERATIONS > UNINSTALL
EQUIPMENT
This command can be used to clear a COMMUNICATION Fail alarm that has been caused by
removing installed equipment (rectifiers, converters, distribution monitors, thermal probes,
batteries monitors).
Alarm Cutoff
This feature is used to silence local audible alarms. Any subsequent Power Critical, Power
Major, or Power Minor alarm will again sound the audible alarm.
When the alarm occurs, the “CUT OFF AUDIBLE ALARM” appears. Press ENTER to turn
off alarms. Then “TURN ON AUDIBLE ALARM” message appears to turn audible alarms
back on.
Control / Operations
Start Lamp Test
Restart Devices
Clear Events
Uninstall Equipment
Control / Operations
Start Lamp Test
Restart Devices
Clear Events
