CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 20
Ringers
Item Specification
Input Voltage -40 to -57 Vdc See Output VA Thermal Limiting.
Nominal Input Voltage -48 Vdc
Input Current 5 A max.
Output
Voltage ac Component
65 to 100 Vac
Factory Default: 100Vac
ac tolerance ± 5 Vac
Regulation ±5% ac component only
dc Offset
Type of ringing
Battery Backed
Ground Backed
Ground Backed no-dc • -40 to +57 Vdc Battery Backed
• +40 to +57 Vdc Ground Backed
• 0 Vdc Offset Disabled
• dc Offset tracks dc Input Voltage
• Factory Default: Enabled
• Battery or Ground Backed is selected by Ringer
Chassis jumper J12 or by external connection of Ring
Rtn to Battery or to Ground. Factory Default: Battery
Backed by Jumper
dc Offset Tracking
Error ± 3 Vdc
Harmonic Distortion 5% THD
Crest Factor 1.21 to 1.51
Output Frequency 15 to 50 Hz
Factory Default: 20 Hz
Frequency tolerance ± 1 Hz
Output
VA 100 VA
Thermal Limiting Output VA may be reduced by reducing Vac when
operating simultaneously above 50°C and less than
-50Vdc input.
Vac is reduced only sufficiently to prevent damage to the
ringer.
Load Power Factor Operating: 0.5 Leading to 0.9 Lagging
No Damage: 0 Leading to 0.7 Lagging
Operating Temperature -40 to +75 °C See Output VA Thermal Limiting.
Heat Dissipation 50 W (170 BTU / hr)
Under Voltage Shutdown 50% of Output Vac Set Point
While shutdown due to external fault, restart will be
performed at approximately 2 minute intervals.
