CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 67
Local and Remote Access Ports
Local Access Connect a laptop PC to a RS-232 port or Ethernet port and access the
controller with EasyView or Web Pages.
Remote Access An RJ-45 Ethernet connector is provided for 10/100 Base-T network
connection to the world wide web (internet) or your enterprise network
(intranet) using Microsoft Internet Explorer®, Mozilla Firefox®, or other web
browser. An optional 56k modem is also available.
Examples of Frequently Used Menu Features:
This section contains a small number of menu navigation examples to help you get familiar with
the menu.
The examples below use shorthand to describe the navigation process. For example, “MENU →
CONTROL / OPERATIONS → START LAMP TEST” means:
Step Action
1 Press to go to the top level Menu.
2
Press navigation buttons to select Control / Operations.
3
Press to select and enter Control / Operations.
4
Press navigation buttons to select Start Lamp Test.
5
Press to execute the Start Lamp Test command.
Lamp Test: MENU > CONTROL / OPERATIONS > START LAMP TEST
Lamp Test allows you to make sure all LEDs and displays in your system are working. This test
lights up all of the LEDs and displays in the system for about ten seconds. Multicolor LEDs light
up multiple colors in sequence, and should be lit for the entire length of the test.
Using the Lamp Test feature is a quick and easy way to see if a system component is
communicating with the system controller. If it responds to Lamp Test, then it is receiving
commands from the controller.
Control / Operations Start Lamp Test
Restart Devices
Clear Events
