System Configuration Table
H5694720
Group
Description Rack
Spaces
Frameworks
102
42 inch tall framework
22U
103
7 foot tall light-duty framework (600 lb zone 4, 1200 lb zone 2)
46U
104
7 foot tall heavy-duty framework (1200 lb zone 4, 1800 lb zone 2)
46U
Battery Tray e/w Anderson Disconnects and 2 Gauge Cable
440
Battery Tray on 7U (12.25”) spacing for 100AH Batteries
7U
450
Battery Tray on 8U (14.00”) spacing for 110-150AH Batteries
8U
470
Battery Tray on 9U (15.75”) spacing for 170AH Batteries
9U
Battery Tray e/w Disconnect Breaker Panel and 2 Gauge Cable
441
Battery Tray on 7U (12.25”) spacing for 100AH Batteries
7U
451
Battery Tray on 8U (14.00”) spacing for 110-150AH Batteries
8U
471
Battery Tray on 9U (15.75”) spacing for 170AH Batteries
9U
Rectifier Shelves with AC Termination Panel
255
Two 5-position Rectifier Shelves, AC Termination Panel and space
for one Group 660 or 661 Distribution Panel
17U
256
Four 5-position Rectifier Shelves, AC Termination Panel and space
for one Group 660 or 661 Distribution Panel
22U
Distribution
660
Distribution Panel e/w Millennium II controller. Distribution
includes 38 positions for bullet style Fuse Holders or Breakers, and 8
positions for equipping Group 600_ Breakers, Fuses or Contactors.
--
661
Distribution Panel e/w Millennium II controller. Distribution
includes 19 positions for bullet-style Fuse Holders or Breakers, 4
TPL-B 0-250A Fuse Holders with Load Shunts, 4 TPS 0-70A Fuse
Holders with Load Shunts, and 8 positions for Group 600_ Breakers,
Fuses or Contactors. (Includes shunt module RPM for monitoring up
to 12 shunts on TPS, TPL-B and TPL-C Fuse Holders)
--
The Following Groups ordered for Group 660 or 661
(8 positions Available)
600B
150A KS22012 Circuit Breaker Kit.
(Breaker e/w 25mV shunt and wiring to connect to RPM)
1-pos
600E
250A KS22012 Circuit Breaker Kit.
(Breaker e/w 25mV shunt and wiring to connect to RPM)
1-pos
600G
400A KS22012 Circuit Breaker Kit.
(Breaker e/w 25mV shunt and wiring to connect to RPM)
2-pos
600M
TPL-C Fuse Holder and 1500A, 50mV load shunt
Kit includes wireset for connecting to shunt RPM
2-pos
600R
6 channel shunt module (RPM) for monitoring shunts on Groups
600B, 600E, 600G and 600M in a Group 660 Panel.
(661 already provides two RPMs). (Mounts on distribution door)
no-pos
600T
800A Low Voltage Battery Disconnect (LVBD) Contactor.
3-pos
