CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 18
Millennium II Controller
General Specifications
Input Voltage Range -48 Vdc (Range: 18-60V)
Maximum Input Power 36W depending upon options
Display Graphic displayed arranged to
8-line by 40-character backlit LCD
Configuration Method Through front panel LCD display and menu keys
Through IBM compatible PC with RS-232 port
Through LAN internet connection
Mounting Requirements Door mounted
Input/Outputs Specifications
Form C Alarm Output Contact Ratings 60VDC at 0.5A
Plant Voltage Measurement
Accuracy
0 to 50 °C (±.05% of full scale + 1
count)
-40 to 85 °C (±0.1% of full scale + 1
count)
Resolution
48V Systems: ±40 mV
48V Systems: ±70 mV
0.01V
Plant Current Measurement
Accuracy
Resolution
0 to +50 °C : ±0.5% of full scale
-40 to +85 °C: ±1.25% of full scale
1A
Temperature Measurement
Accuracy
Thermistor temperature
One-Wire Serial probes
Resolution
-5 to +55 °C: ±2°C
-40 to +85 °C: ±3°C
-5 to +55 °C: ±1°C
-40 to +85 °C: ±3°C
0.1°C
4-20mA Input Monitor
Accuracy
Resolution
±100µA
±10.0µA
General (0-5V) Input
Accuracy
Resolution
0 to +50 °C: ±0.5% of full scale
-40 to +85 °C: ±1.0% of full scale
0.01VDC
