CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 114
Bullet Style Load Circuit Breakers
Part # Amperage CB Positions Min Wire Ga
407998137 3 1 10
407998145 5 1 10
407998152 10 1 10
407998160 15 1 10
407998178 16 1 10
407998186 20 1 10
407998194 25 1 10
407998202 30 1 10
408213486 40 1 8
407998210 45 1 8
407998228 50 1 6
407998236 60 1 6
407998244 70 1 2
407998251 80* 1* 2
407998269 90* 1* 2
407998277 100* 1* 2
408185353 125 2 2
408185346 150 2 1/0
Note: * 80, 90 and 100A Breakers require one adjoining space be left unoccupied
TPL-B and TPL-C Fuses
Part # Amperage Min Wire Ga
405673161 0.5A Alarm Fuse
TPL-B Fuses
406794776 70 6
408239648 80 4
406794784 100 2
406925685 125 1/0
406794792 150 2/0
406794818 200 4/0
406794982 225 4/0
406794842 250 4/0
TPL-C Fuses
406794867 300 (2) 4/0
406794875 400 (2) 4/0
406794883 500 (2) 4/0
406794891 600 (2) 350
