CPS6000-M2 Installation Guide H5694720
Issue 8 January 2008 19
Rectifiers
Item Specification
Nominal Output Voltage 48/52/54.5 Vdc
Operating Output Voltage
Ranges 42 to 58 Vdc
Boost Voltage 48 to 58 Vdc
Output Current QS861A: 0 to 15A at 54.5V
QS862A: 0 to 30A at 54.5V
QS852A: 0 to 20A at 54.5V
QS853A: 0 to 25A at 54.5V
QS864A: 0 to 40A at 54.5V
QS865A: 0 to 50A at 54.5V
Nominal Input Voltage QS861A: 100/120/208/240
Vac
QS862A: 100/120/208/240
Vac
QS852A: 208/240 Vac
QS853A: 208/240 Vac
QS864A: 208/240 Vac
QS865A: 208/240 Vac
Input Voltage Ranges QS861A: 85 to 275 Vac
(Shutdown from 135 to
150V)
QS862A: 85 to 275 Vac
(Shutdown from 135 to
150V)
QS852A: 150 to 275 Vac
QS853A: 150 to 275 Vac
QS864A: 150 to 275 Vac
QS865A: 150 to 275 Vac
Input Current QS861A: 8A at 120 Vac
4.4A at 208 Vac
QS862A: 13A at 120 Vac
8.8A at 208 Vac
QS852A: 7.4A at 208 Vac
QS853A: 7.4A at 208 Vac
QS864A: 11.8A at 208 Vac
QS865A: 14.5A at 208 Vac
Operating Frequency Range 45 to 66 Hz
Operating Temperature -40 to +65 °C
Output Voltage Regulation ±0.5%
Output Noise, Ripple 250 millivolts peak to peak maximum, over the range dc to
100 MHz
Load Share Accuracy 1.5A maximum deviation between rectifiers
Heat Dissipation at Full Load QS861A: 141W (480 BTU) per rectifier at 120 Vac operation
160W (546 BTU) per rectifier at 240 Vac operation
QS862A: 177W (604 BTU) at 100 to 120 Vac operation
212W (724 BTU) at 200 to 240 Vac operation
QS852A: 133W (454 BTU) per rectifier at 240 Vac operation
QS853A: 151W (515 BTU) per rectifier at 240 Vac operation
QS864A: 240W (819 BTU) per rectifier at 240 Vac operation
QS865A: 267W (911 BTU) per rectifier at 240 Vac operation
Selective High-Voltage
Shutdown Above 58 Vdc
Backup High-Voltage
Shutdown Above 60 Vdc for 1 millisecond
