Overview
Manual Documentation Number:pn7515_ ZlinxIO-0712m 3
RECOMMENDATION – It is recommended to inspect the Sealed Relays periodically and to check for any degradation of the
materials and to replace the product, not the Sealed Relays, if any degradation is found.
Relay Types JS-5N-K, JS-5-K, JS-6N-K or JS-6-K manufactured by Takamisawa Electric Co Ltd., rated 10A, 250VAC, 10A,
30VDC,utilizes the following materials to maintain sealed device properties:
Manufacturer Type
Relay Case Mitsubishi Engineering Plastics
Corp. 5010GN6-30(r2)
Mitsubishi Engineering Plastics
Corp. 5010GN6-30M8(cc)(r2)
Mitsubishi Engineering Plastics
Corp. 5010GN6-30 M8AM
Relay Base Mitsubishi Engineering Plastics
Corp. 5010GN6-30M8(cc)(r2)
Mitsubishi Engineering Plastics
Corp. 5010GN6-30 M8AM
Sealant Eccobond A-316SC
Relay Type APF-30305, manufactured by Panasonic Electric Works, rated 277VAC, 8A, 24VDC, 6A general use utilizes the
following materials to maintain sealed device properties:
Manufacturer Type
Relay Case Wintech Polymer Ltd. CN7030MFBD
Relay Base Wintech Polymer Ltd. CN7015MFD
Sealant Resinous Kasei Co. Ltd. A-2500BK
1.5 About this manual
This manual has been created to assist you in installing, configuring, and using your Zlinx Wireless I/O modules. Please read
it carefully and follow the instructions to achieve best results.
The manual is divided into 11 major sections as follows:
Table of Contents
The table of contents is hypertext linked in the electronic documentation. This allows rapid navigation to each chapter.
Overview
Overview section gives a general information on product standards compliance, prerequisites and safety information.
Product Introduction
This section covers package contents, and main features of the Zlinx Wireless I/O products. This section also contains
information on radio frequency basics.
Hardware Information
In this section Zlinx Wireless I/0 modules are described in details. The section covers information on I/O options and
characteristics and wiring instructions.
Getting Started
This section guides you through the installation process. Two main modes of operation: Peer-to-Peer mode and Modbus
mode are introduced in this section.
Configuration and Operation
Information on configuring Zlinx Wireless I/O is provided in the section. Information on settings for Peer-to-Peer and Modbus
mode can be found in this section.
