Appendix B: Product Specifications
Manual Documentation Number: pn7515_ZlinxIO-0712m
71
A
A
p
p
p
p
e
e
n
n
d
d
i
i
x
x
B
B
:
:
P
P
r
r
o
o
d
d
u
u
c
c
t
t
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
Base Module Models: ZZ24D-NA-SR, ZZ24D-NB-SR, ZZ24D-NC-SR, ZZ24D-
ND-SR
ZZ24D-NA-MR, ZZ24D-NB-MR, ZZ24D-NC-MR, ZZ24D-
ND-MR
ZZ9D-NA-MR, ZZ9D-NB-MR, ZZ9D-NC-MR, ZZ9D-ND-
MR
ZZ9D-NA-LR, ZZ9D-NB-LR, ZZ9D-NC-LR, ZZ9D-ND-LR
ZZ9D-NA-LR-AU, ZZ9D-NB-LR-AU, ZZ9D-NC-LR-AU,
ZZ9D-ND-LR-AU;
ZZ8D-NA-LR, ZZ8D-NB-LR, ZZ8D-NC-LR, ZZ8D-ND-LR
Expansion Module
Models:
ZZ-4AI, ZZ-4AO, ZZ-2AI2AO, ZZ-8DI-DC, ZZ-8D0-T,
ZZ-8D0-T1, ZZ-4DI4DO-DCT, ZZ-4DI4DO-DCT1,
ZZ8DO-R, ZZ4RTD1, ZZ-4AO-2
Manual: Electronic version of this manual, PDF available
CD-ROM disc: Zlinx Manager
PDF of Zlinx Wireless I/O User Manual
PDF of Quick Start guide
Operating Systems
supported:
Windows 2000/XP, Windows 7
Dimensions: 1.15 x 3.65 x 5 in (2.92 x 9.27x 12.7 cm)
Expansion Feature: 1 Base Module and up to 6 Expansion Modules
Radio Properties
Short Range (SR)
Option:
Up to 300 ft indoors / 1 mile outdoors (LOS)
Medium Range (MR)
Option:
Up to 1500 ft indoors / 7 miles outdoors (LOS)
ZZ9D-Nx-LR-xx Option Up to 1500 ft indoors / 7 miles outdoors (LOS)
ZZ8D-Nx-LR Option: Up to 1800 ft indoors / 25 miles outdoors (LOS)
Antennas: For 2.4 GHz models: 4.25 inch omni-directional rubber
duck antenna. PN: ZZ24D-ANT1
For 900 and 868 MHz models: 6.5 inch omni-directional
rubber duck antenna. PN: ZZ9D-ANT1
LED Indicators
Receive Signal Strength
Indicator:
Tri-color LED (Off = no signal, Red = weak, Yellow =
OK, Green = Strong)
RF Data Indicator: Green LED (blinks with TD or RD data traffic, Off = no
data traffic)
Bus Indicator: Green LED (blinks with TD or RD data traffic, Off = no
data traffic)
Power Indicator: Red LED
I/O Connectors: Removable screw terminal blocks: 2 position: 3,81mm
spacing; 3, 4 and 8 position: 3.5 mm spacing
Digital Inputs
Voltage Range: 0 to 48 VDC
Low Voltage (0): 0.8 VDC maximum
High Voltage (1): 4.0 VDC minimum
Pull up/down current: 38uA
